FST-H-48100
FIRST POWER
Lithium-ion
External Hi-Protection
CE, UL, FCC
Forklift
Multiple Input
Multiple Outputs
Product Advantage
1.This charger is certified with CE, UL, FCC, CSA, KC etc, and complies with relevant requirements for electromagnetic compatibility and safety.
2.Touch and leakage current values remain within required limits, without further measures.
3.The power factor is 0.99, therefore the available mains power is used to the maximum.
4.The charging current contains a very low ripple.
5.Charging from three-phase outlet.
6.Parallel connection of several chargers is possible, in order to achieve higher charging power.
7.Highly efficient (Max 95%).
8.Core Power Module is IP 65 Protection level, robust against dust, humidity, vibration etc.
SPECIFICATION
AC input | FST-H-36100-3AF-XX-X | FST-H-36150-3AF-XX-X | FST-H-48100-3AF-XX-X | FST-H-48150-3AF-XX-X | FST-H-80100-3AF-XX-X | FST-H-9680-3AF-XX-X | FST-H-96100-3AF-XX-X | FST-H-15060-3AF-XX-X | FST-H-20045-3AF-XX-X | FST-H-31030-3AF-XX-X | FST-H-35025-3AF-XX-X | FST-H-62015-3AF-XX-X |
Input Voltage | 3P 220/240/380/440/480VAC | |||||||||||
Max. input current | 15/30A | |||||||||||
Input frequency | 45-65HZ | |||||||||||
Max. Input power | 5.5KW/ 10.5KW | |||||||||||
Power factor | > 0.99 | |||||||||||
X capacity | 0.68µF / 6.6µF | |||||||||||
Y capacity L1 PE | 15.1nFX3 / 16.3nFX3 | |||||||||||
DC output | ||||||||||||
Suitable for Lithium Batteries | 36V | 36V | 48V | 48V | 80V | 96V | 96V | 150V | 200V | 310V | 350V | 620V |
Suitable for Lead-Acid Batteries | 36V | 36V | 48V | 48V | 84V | 96V | 96V | 144V | ||||
Output Voltage range | 15-49VDC | 15-49VDC | 20-66VDC | 20-66VDC | 35-115VDC | 40-132VDC | 40-132VDC | 58-193VDC | 78-257VDC | 120-400VDC | 135-450VDC | 240-800VDC |
Charging voltage accuracy | 0.5% | |||||||||||
Charging current accuracy | 0.5%FS | |||||||||||
Max. charging current (3 phase) | 100A | 150A | 100A | 150A | 100A | 80A | 100A | 60A | 45A | 30A | 25A | 15A |
Max. charging power (3 phase) | 7KW | 10KW | ||||||||||
Efficiency | Up to 95% | |||||||||||
The FST-H 48V 100A Portable Charger is a high-performance charging solution designed for electric industrial vehicles like forklifts, AGVs, and other heavy-duty machinery. It offers 100A of charging power, ensuring fast and efficient charging cycles for lithium and lead-acid batteries, ultimately reducing fleet downtime and improving operational efficiency.
Built with IP65 protection, this charger is durable and reliable, even in harsh environments. It features a charging voltage range of 20-66VDC, providing precise and safe charging for 48V battery systems with a charging voltage accuracy of 0.5% and current accuracy of 0.5%. The charger also includes phase-loss protection, overvoltage, undervoltage, and short-circuit protection to ensure safe and reliable operation.
With fan-based cooling, the charger performs optimally during extended use, and its up to 95% efficiency helps lower energy consumption and operational costs. The FST-H 48V 100A is designed for use in temperatures ranging from -40°C to 55°C, and it can operate at altitudes of up to 4000 meters. Fully CE, FCC, and TUV certified, this charger meets international standards for safety and reliability, making it an ideal solution for your industrial charging needs.
